Riferimento: UHA25XL
Marca: HARTKE
HARTKE 2.5 XL BASS CABINET
HARTKE 2.5 XL BASS CABINET
Specifiche Generali
Nominal diameter: 15", 381mm
Power rating: 300W
Nominal impedance: 4ohm
Sensitivity: 96dB
Magnet type: Ferrite
Voice coil diameter: 2.5", 63.5mm
Coil material: Copper
Cone material: Kevlar loaded paper
Former material: Polyimide
Surround material: Cloth-sealed
Frequency range: 42-3500Hz
Xmax: 0.16", 4.25mm
Gap depth: 0.31", 8mm
Voice coil winding width: 0.64", 16.5mm
Parametri di Thiele-Small
D: 0.33m/12.99in
Fs: 48.1Hz
Mms: 82.39g/2.91oz
Qms: 2.99
Qes: 1.004
Mmd: 68.24g/2.41oz
Qts: 0.751
Re: 3.15ohm
Vas: 137.7lt/4.86cu.ft.
BI: 8.83Tm
Cms: 0.133mm/N
Rms: 8.327kg/s
Le (at 1kHz): 0.45mH
Informazioni di Montaggio
Cut-out diameter: 13.8", 351mm
Diameter: 15.2", 385mm
Mounting slot dimensions: 0.36x0.24", 9.2x6.2mm
Mounting slot PCD: 14.5", 369mm
Number of mounting slots: 8
Overall depth: 6.4", 162mm
Unit weight: 10.6lb, 4.8kg
Per stampare la scheda prodotto, clicca qui
Per una panoramica su tutta la serie Celestion Bass Ferrite, clicca qui
Per consultare e scaricare la brochure originale Celestion Guitar&Bass, clicca qui
